Brand : HEIDENHAIN
LIP 581 / 581C
-
The HEIDENHAIN LIP 581 is an incremental linear encoder with very high accuracy for large measuring lengths with 1Vpp output signal.
- Request A Quote
Description
The HEIDENHAIN LIP 581 is available in multiple travels and accuracy grades using DIADUR glass and grating period of 4µm, offering the following features…
- DIADUR phase glass
- Measuring lengths from 70mm to 1440mm
- Signal period of 0.8um to 0.4um
- Measuring steps of 1 230m to 0.5µm (without interpolation)
- 1Vpp output signal
- Accuracy grade of ±1µm
- Reference mark - one on 571R
