Brand : HEIDENHAIN
ROC 415
-
HEIDENHAIN ROC 415 absolute singleturn encoders offer a 6mm dia shaft and either EnDat or SSi interfaces.
- Request A Quote
Description
HEIDENHAIN ROC 415 absolute encoder, 6mm dia shafts, ±10" accuracy, SSi and EnDat interfaces.
ROC 400 series absolute rotary encoders with integral bearing
- Solid shaft for separate shaft coupling
- Very high positioning accuracy of down to ±10"
- Available with stainless steel housing
- Max. operating temperature: 100 °C
- 33 554 432 positions/rev.
- Multiturn functionality for up to 4096 revolutions
- Interfaces: EnDat, Fanuc, SSI and DRIVE-CLiQ
- Housing diameter ≈ 56 mm
